Tekpower TP-3003D Digital Variable Linear-Type DC Power Supply, 0-30 Volts @ 0-3 Amps with Alligator and Banana Connector Cable

  • $69.99
    Unit price per
Shipping calculated at checkout.

The Tekpower TP3003D variable DC power supply is a compact and affordable instrument that is suitable for both home and industrial use. This digital DC power supply has maximum output voltage of up to 30 volts and current up to 3 amps. It comes with rotary switches for setting up the voltage and current. With its reliability and versatility, it's an invaluable and indispensable tool for testing, science project and etc., ideal for labs, research institutes, R & D facilities.

  • Linear Output High precision DC regulated power supply with 0-30 volts and 0-3 amp outputs
  • Two operational modes: constant voltage and constant current
  • Cooling fan automatic activation by built-in thermo-sensor
  • Back-lit LCD Display with a 0.1V and 0.01A resolution

What’s in the Box:

  • TP3003D power supply
  • Power cord
  • Test leads with alligator clips (28 inches long)
  • User manual

Output DC Voltage: 0.0 – 30.0V
Output DC Current: 0.00 – 3.00 A
Input Voltage: 110V/AC, 60Hz
Voltage and Current adjustment
Voltage regulation: CV < 0.01% + 3mV, CC < 0.2% + 6 mA
Load regulation: CV < 0.01% + 3mV, CC < 0.02% + 3mA
Ripple and noises: CV < 1 mV rms, CC < 3 mA, rms
Protection: High current limiting
Operating Temperature: 0 - 102 °F (0 - 40 °C), Relative Humidity: < 80%
LCD Accuracy is within +/- 2.5%
Size: 9 ½ x 6 x 3 ¾ inches
Weight: approx. 14 lbs

Linear Power Supply is a traditional Power Supply with Transformer inside, there is much less noise than the switching power supply, it is quiet and stable thank the switching power supply.
